Top view of the rear engine deck of the M36B2 tank destroyer from TM 9-745: 90-mm Gun Motor Carriage M36B2, War Department Technical Manual, July 1945:
A-GUN TRAVELING LOCK
B-LIFTING HOOKS
C-LEFT TAILLIGHT
D-ENGINE COMPARTMENT DOORS
E-ENGINE COMPARTMENT LEFT COVER PLATE
F-LEFT WATER EXPANSION TANK FILLER CAP COVER
G-LEFT FUEL TANK FILLER CAP COVER
H-FIRE EXTINGUISHER EXTERIOR PULL HANDLES
J-LEFT (LC) ENGINE LUBRICATING OIL TANK FILLER CAP COVERK-RIGHT (LA) ENGINE LUBRICATING OIL TANK FILLER CAP COVER
L-AUXILIARY GENERATOR FUEL TANK FILLER CAP COVER
M-RIGHT WATER EXPANSION TANK FILLER CAP COVER
N-RIGHT FUEL TANK FILLER CAP COVER
P-ENGINE COMPARTMENT RIGHT COVER PLATE
Q-ENGINE COMPARTMENT REAR COVER PLATE
R-RIGHT TAILLIGHT
