M26 Armored Tractor

Diagrams of the M26 armored tractor from TM 9-767: 40-Ton Tank Transporter Truck-Trailer M25, War Department Technical Manual, U.S. War Department, February 1944. The M25 Tank Transporter, nicknamed the “Dragon Wagon,” was a heavy tank transporter and tank recovery vehicle used in World War II. The M25 was composed of the M26 6×6 armored tractor and M15 40-ton trailer.

m26-tractor-truck-dragon-wagon-front-view

m26-tractor-truck-dragon-wagon-rear-view
