155-mm Gun on Gun Motor Carriage M40

Posted on April 29, 2011 by Lone_Sentry_Admin

Two views of the U.S. 155-mm Gun on Gun Motor Carriage M40 from TM 9-350, the Technical Manual on the 155-mm Gun M2 printed in 1945.

155-mm Gun on Gun Mount M13 on Gun Motor Carriage M40 -- Side View

155-mm Gun on Gun Mount M13 on Gun Motor Carriage M40 — Side View

155-mm Gun on Gun Mount M13 on Gun Motor Carriage M40 -- Rear View

155-mm Gun on Gun Mount M13 on Gun Motor Carriage M40 — Rear View
